SSB-TM Mounting Kits
1t, 2t, 5t, 10t

Overview

Explanation;
Avoids toppling or displacement of the load with the ground fixing system  Corrects off-center loads  Protects the load cell against side forces  Protects the load cell against leakage currents with a grounding cable

Features;

  • In medium capacity tank and silo weighing applications, In non-impact and non-trembling reactor weighing applications are used.

Technicial Specifications

Specifications;

  • Conveys the load directly to the center of the load cell thanks to its special design
  • The upper plate can move in every direction such that undesired twistings of the load cell are eliminated
  • Load cell has been mounted using highly strong bolts (8.8)
  • Protects the load cell against leakage currents thanks to the grounding cable placed between the lower and upper plates
  • Made of reinforced steel, and electro-galvanized and painted against corrosion

Documents

Documents

SSB-TM 1-2T Mounting Kit Technical Drawing (.pdf)

SSB-TM 5T Mounting Kit Technical Drawing (.pdf)

SSB-TM 10T Mounting Kit Technical Drawing (.pdf)

SBS-TM Mounting Kits Apllication Graphic (.pdf)

You can use the VariCad program to open 2D & 3D technical drawings.
